Customizing POS Terminal

250

Smart design to enhance brand value

A POS system that was first released overseas and
validated for customers looking for a new solution.

    KEY FEATURE 01

    SMOOTH STABILITY AND
    FREE SPACE

    The 250 series has increased space management allowing for a cleaner look.
    The curved stand gives a soft sense of stability while also allowed peripheral devices
    such as printers, payment machines, and scanners to be inserted right below
    the main screen for convenience.

    KEY FEATURE 02

    SUPPORTS
    HIGH-PERFORMANCE
    SPEAKERS

    Supports high-performance speakers for delivery.

    KEY FEATURE 03

    TWO-TONE COLOR
    COMBINATION

    The two-tone color combination of black and white
    enhances the atmosphere of the space in the front.

    KEY FEATURE 04

    SIMPLE STRUCTURE

    A three stage structure allows for easy disassembly and
    assembly with convenient maintenance.

    KEY FEATURE 05

    POWERFUL, HIGH-PERFORMANCE
    PROCESSORS

    Featuring Intel®'s high-performance processors (CORE™ i3/i5/i7, Celeron®), you get a faster, more reliable, and powerful performance.
    The 250 model delivers approximately 3 times more than the J1900 processor and 15% more CPU performance than the i3.

    4GB up to 32GB

    Optional

    128GB up to 512GB

    Optional

    Windows 10 IoT

    OS

    KEY FEATURE 06

    SAME STABILITY AND FEATURES AS THE 200 SERIES

    As technology has advanced throughout the years, we have applied
    the technology that meets the needs and trends from throughout the years.

    KEY FEATURE 07

    GLASS TOUCH PANEL

    • ·Safe from scratches
    • ·Keeps the screen clean for a long time
    • ·Reduces eye strain
    KEY FEATURE 08

    STRENGTHEN PROUCT RELIABILITY
    SUPER HEAT DISSIPATION FRAME DESIGN

    • ·Aluminum frame designed for CPU heat dissipation
    • ·Ensuring the internal parts last for a lifetime
    KEY FEATURE 09

    SECURE AND SIMPLE STRUCTURAL
    DESIGN

    Power plug-type secure fastening
    design prevents reverse current
    One cable construction (power cable,
    video cable, and touch all in one cable)

    * Dual hinge patent and hinge design patent confirmed

    SSD sliding structure design allows
    for easy SSD replacements

    * Patent application pending

    KEY FEATURE 10

    VARIOUS I/O INTERFACES PROVIDED
    6 SERIAL, 6 USB

    1. 01
      Industry's first multi-monitor support
      (HDMI, DVI, DisplayPort, VGA)
    2. 02
      Power all serial ports
      (Powered Serial)
    3. 03
      Supports multiple forms of Serial Port
      (DB9, RJ45/50)
    • Upper I/O Interfaces
    • Lower I/O Interfaces

    Display Options

    YOU CAN SELECT AND USE VARIOUS COMBINATIONS

    OPTION 01
    Main Display + Secondary Display
    • 15” + 15”
    • 15” + 9.7”
    • 15”

    MEET THE 15.6” FHD
    MAIN SCREEN

    The 15.6”, 1920 x 1080 high-resolution FHD main screen offers a larger, clearer screen.
    Provides high-quality images that you can view with just a glance.
    LED strips are located on the left and right sides of the screen and
    when the power button is pressed, both sides are illuminated in green.

    A SOPHISTICATED
    COLOR

    All dark gray color.
    We created a sophisticated space image with all dark gray colors.

    Peripheral Options

    MSR

    · Simple assembly allows you to select left
    and right installation

    VFD

    20 columns × 2 lines

    Alphabet & Numeric

    SOLUTIONS

    Different UP solutions for your store

    The program can be configured according to the store’s concept and the user friendly UI provides a quick operation
    from an order being placed to payment. Multiple languages are supported and local businesses can also be linked.

    UP SOLUTIONS

    Specifications

    N-250
    System
    System
    Processor
    Intel® Processor N97, up to 3.60 GHz(Fanless)
    Chipset / BIOS
    Intel® Alder Lake-N SoC / AMI UEFI
    Storage
    2.5" SATA III SSD 128GB (SSD 256/512GB, optional)
    Memory
    4GB SO-DIMM
    DDR4 3200MHz x 1 (Max 16GB, optional)
    Graphics
    Intel® UHD Graphics
    OS
    Windows 10 IoT Enterprise(64bit), Windows 11(64bit)
    Display
    Display
    Primary Display Type
    15" LED Backlight (1024 x 768 Resolution)
    Touch
    PCAP 10 Point Multi-touch
    I/O Interfaces
    I/O Interfaces Rear Top & Bottom Ports
    USB
    2 x USB 2.0 (Rear Top x 2), 1 x USB 2.0 (RJ11), 4 x USB 3.0 (Rear Bottom x 4)
    Serial
    6 (DB9 x 3, RJ50 x 2, RJ11 x 1)
    Audio
    1 x Audio-out / 3.5mm
    Extend Displays
    1 x DP output
    LAN
    1 x RJ45 (Base-T 10,100,1000m/bps Ethernet)
    Speaker
    1 x 3W
    Peripheral Options
    Peripheral Options
    Secondary Display
    • LCD Type: 9.7" or 15" LCD (USB Port x 1)
    • Touch Monitor: 9.7" or 15" LCD with Capacitive Touch (USB Port x 1)
    - by single cable(no power & USB cable)
    Customer Display (CDP)
    FSTN LCD Type(20 columns x 2 lines)
    Card Reader (MSR / SCR)
    Smart Card Reader: ISO/IEC7816 EMV Level 1 / Magnetic Stripe Reader: ISO 7811 ID-1 All
    tracks *Interface: USB(HID) and RS232C(COM6)
    Dallas Reader
    Dallas Reader(i-button): 6 characters / prefix and suffix
    *Interface: USB(HID) and RS232C(COM6)
    Physical Dimension
    Physical Dimension
    Dimension (W x D x H)
    362 x 237 x 357 (mm)
    Weight
    4.5 kg
    Box Dimension
    Box Dimension
    Dimension (W x D x H)
    430 x 290 x 430 (mm)
    Weight
    6.3 kg
    Environment
    Environment
    Power Supply
    DC 12V/5A (AC 100V~240V, 60W)
    Temperature
    Operating Temp : 0~40℃ / Storage Temp : -20~60℃ / Humidity : 10% to 90%
    Certifications
    CE, FCC, KC

    *Specifications are subject to change without prior notice.



    Download

    Catalog
    • 250 POS SYSTEM
      v05EN(202411) ENG 1.5MB 20241125

      Download
    • 250(N97) - better heat dissipation
      v1.3(202507) ENG 0.9MB 20250701

      Download
    Manual & Guide
    • NOVA POS_Installation Guide
      v1.1(202508) ENG 5.3MB 20250822

      Download
    Drivers

    1. Product information can be modified to improve appearance and product performance.

    2. Product specifications are subject to change without prior notice to improve performance.

    3. The weight of the box varies depending on the components and the main board. (includes box weight)

    4. Product images are produced for better understanding and may not be real.
